NGC 6445

Combination of 3, 3 minute exposures, SBIG ST-4 CCD
300mm f/6 newtonian at prime focus.

NGC 6445 is a fairly small and moderately bright planetary nebula in Sagittarius, about 3 degrees south-west of M23. It is visible as a faint patch of light in an 8" telescope, while a trace of the ring shape can be made out in a 12" under very good conditions. Also visible in the same moderate magnification field is the small globular cluster, NGC 6440.

Combination of 10, 2 minute exposures, SBIG ST9XE CCD camera.
300mm f/6 newtonian telescope at prime focus.

Combination of 5, 3 minute images unfiltered.
SBIG STL-1001E CCD. 20" f/6.8 Dall-Kirkham cassegrain telescope at prime focus.
