M13 NGC 6205

Object Type Globular Cluster
Constellation Hercules
Magnitude 5.8
Size 20.0' x 20.0'

Considered to be the best of the globular clusters for northern hemisphere observers, M13 in Hercules, is a large and bright object that provides a good view even in a small telescope. It is one of the showpieces of the northern sky and has probably been studied more than any other globular.

Perhaps not so well known about M13 is that there are a large number of faint galaxies in the same field. The brightest of these is NGC 6207, which is situated about half a degree to the north east of M13. It is visible in the photograph a short distance to the upper left of M13. How many observers have ever looked at this object after looking at M13? At magnitude 12, it should be a very easy object for a 6" telescope.


Film Images



45 minutes exposure, using Fuji Superia 400 film.
5" f/5 refractor at prime focus.


DSLR Images



Combination of 5, 120 second images. Modified Canon Digital Rebel DSLR camera.
5" f/5 refractor at prime focus.


CCD Images


Combination of 5, 1 minute images, SBIG ST-7XE CCD.
8" f/6.3 schmidt-cassegrain at prime focus.


Combination of 11, 1 minute images, SBIG ST-9XE CCD.
16" f/10 schmidt-cassegrain with an f/6.3 focal reducer.


Combination of 5, 2 minute images using red and green filters, and 7, 2 minute images using a blue filter.
SBIG ST-9XE CCD. 10" f/6.3 schmidt-cassegrain at prime focus.


Combination of 15, 1 minute images unfiltered.
SBIG STL-1001E CCD. 20" f/6.8 cassegrain at prime focus.
