Abell 39
PK 47 +42.4


Combination of 10, 3 minute exposures, SBIG ST-9XE CCD.
16" f/10 schmidt-cassegrain with an f/6.3 focal reducer.

Abell 39 is a large planetary nebula in Hercules, about 10 degrees south and about 3 degrees west of the globular cluster, M 13. Like all Abell planetaries, it has a very low surface brightness, although not as bad as many. The magnitude is quoted as 13.7, but it is a relatively small 2.9 arc minutes in diameter, making the nebula slightly brighter than most Abell planetaries.


Combination of 10, 3 minute exposures.
SBIG STL-1001E CCD. 20" f/6.8 Dall-Kirkham cassegrain telescope at prime focus.
